Liquid Filling Equipment and Depositors

!

Masterfil Stainless Steel Bench Top Volumetric Filler

Variable fill capacity from approx. 250ml to approx. 1300ml. Diving nozzle for bottom fill. Adjustable for piston fill / discharge speed, nozzle rise and fall plus nozzle rise dwell time between cycles. Foot pedal operation.

Masterfil Stainless Steel 5 Litre Volumetric Filler

Diving nozzle to fill up to 5 litres in single and multiple shot. Pneumatically actuated. Mobile stainless steel base unit. Stainless steel fill table.

Tritech Stainless Steel Semi-Automatic Volumetric Container Filler

Diving nozzle to fill up to 5 litres and multiple shot.

Neumo type SAF80 5 Litre Filling Machine

Single head with diving nozzle. Pneumatic operation with foot pedal actuator. Mounted on mild steel mobile frame.

Riggs Autopack Single Head Stainless Steel Depositor

Stainless steel pneumatically actuated depositor with 250-litre stainless steel agitated hopper 700mm dia X 520mm deep on straight plus 380mm Deep cone section. Removable two-piece flat top. Gate type agitator with 0.37kW 415/3/50 motor and gearbox. Mounted on mobile stainless steel support frame. Ex food use.

Permex Panda Pneumatic IBC / Drum Filler

Volumetric filler with mechanical flowmeter and control panels. Pneumatic arm lift / lower and raise. Last used on lubricating oils
